#1 Somewhere on the Way to UI5, We Lost RTTS

ABAP developers have always built screens for tables whose structure is unknown when the code is written. With ALV you either assemble the field catalog yourself and hand it to the iconic CL_GUI_ALV_GRID, or you let CL_SALV_TABLE do it for you:

cl_salv_table=>factory( IMPORTING r_salv_table = DATA(lo_alv)
                        CHANGING  t_table      = <lt_any> ).
lo_alv->display( ).

Two statements, any internal table, no type known at design time. RTTS reads the structure at runtime, the field catalog follows from it, DDIC labels come along for free.

Data browsers, table maintenance, migration cockpits, generic reports — a whole category of tooling was built that way, and the generality was the requirement, not a trick.

Model Definition at Design Time — OData

When you build a UI5 app today, the path from backend to frontend goes through a typed OData service. That holds for freestyle UI5, for Fiori Elements, and for a fully backend-driven RAP application with a consumption view. The shape of the model is decided when the code is written and baked into the contract.

[image: RESTful APIs in a simple and standard way — odata.org]

And that is powerful! The point of OData is that a client can trust the API and discover everything it needs from the metadata document — it does not have to know SAP at all. Whenever you do not know the client, or the client does not know your backend, that contract is exactly what you want.

Model Definition at Runtime — RTTS

But some use cases do not know the model at design time either. Think of SE16 or SE16N: the whole point is to display any table.

There the contract buys nothing. Backend and frontend are tightly coupled, one team builds both, and the client knows the system intimately — anything resting on design-time metadata is aimed at a different problem.

The model is assembled at runtime, and in ABAP that can be done with RTTS, a service nearly every ABAP developer already knows (the reading half is RTTI):

[image: RTTS — read metadata at runtime]

But how do we get that data into a UI5 app?

Luckily, UI5 apps do not actually require OData — a JSONModel can be filled from any plain HTTP endpoint, so nothing stops a request from carrying a different model shape every time.

And that is one of the use cases abap2UI5 is built for.

Data Binding at Runtime with abap2UI5

In abap2UI5, views are just strings the application builds, and the model is bound from ABAP data — including data whose type only exists at runtime. A view that draws any table looks like this:

" tab is TYPE STANDARD TABLE - filled however you like, a SELECT, a function
" module, an EML read. Only its type matters from here on.
METHOD render_any.

  DATA(comps) = CAST cl_abap_structdescr(
                    CAST cl_abap_tabledescr(
                        cl_abap_typedescr=>describe_by_data( tab )
                      )->get_table_line_type( ) )->get_components( ).

  DATA(ui_table) = parent->ele( `Table`
                       )->a( n = `items` v = client->_bind( tab ) ).

  " one column per component - discovered, not declared
  DATA(columns) = ui_table->ele( `columns` ).
  LOOP AT comps INTO DATA(comp).
    columns->ele( `Column`
        )->ele( `header`
            )->tag( `Text`
                )->a( n = `text` v = comp-name ).
  ENDLOOP.

  " one cell per component, bound by field name
  DATA(cells) = ui_table->ele( `items`
      )->ele( `ColumnListItem`
          )->ele( `cells` ).
  LOOP AT comps INTO comp.
    cells->tag( `Text`
        )->a( n = `text` v = |\{{ comp-name }\}| ).
  ENDLOOP.

ENDMETHOD.

No entity type, no CDS view, no service binding — and no field name anywhere in the view. The columns are whatever the table happens to have, and the binding paths are the component names RTTI just handed back. Go one step further and comp-type will tell you whether a component is a DDIC type, which is where the real labels come from — the field catalog, rebuilt from the same source it always came from.

Full source: Z2UI5_CL_SMP_APP_497, one of the abap2UI5 samples, so it is compiled and linted on every commit.

A table nobody described, drawn from whatever the data turned out to be. Doesn't that look a bit like cl_salv_table in a UI5 view? 😉

You can go further and build a full SE16-flavoured app — have a look at the se16n addon.

Nothing Here Is Exotic

Both halves stay inside the conventions you already work in, which is what makes this cheap to adopt and cheap to hand over.

The frontend is a freestyle UI5 app using sap.m controls, XML views, a JSONModel and two-way binding — nothing proprietary, and nothing you have not written before. The backend is a global ABAP class: one interface, in a package, travelling in a transport, compiling on ABAP Standard and ABAP Cloud alike.

What It Costs

A generic table has no contract, and that is a real price. Nothing external can depend on it, nothing announces that the underlying structure changed, and a locally defined structure gets technical names instead of labels.

So this is not an upgrade over a typed service. One answers what a foreign system can depend on for the next five years; the other, what an internal tool should show a user right now, given a structure it was handed a millisecond ago.

Conclusion

RTTS never went away. cl_abap_structdescr is still there, and it is released in ABAP Cloud too. Only the screen in front of it did.

abap2UI5 can give runtime-typed ABAP a UI5 face again by binding ABAP data directly, so data typed at runtime is not a special case. It is just data — the way it was in the old SALV and field-catalog days.

abap2UI5 is open source, runs on-premise and in the cloud, and sits beside what you already operate. Put an abap2UI5 app into the launchpad and no user can tell it from the RAP and freestyle UI5 tiles next to it.

So next time you reach for RTTS and need a UI, give abap2UI5 a try. It may be a good complement to the UI5 solutions you already run.

Happy ABAPing! 🦖🦕🦣
