Hello World ​

This is the class from In a Nutshell, now in your own system. Create a class named ZCL_APP_HELLO_WORLD and copy this into it:

abap
CLASS zcl_app_hello_world DEFINITION PUBLIC.
  PUBLIC SECTION.
    INTERFACES z2ui5_if_app.

  PROTECTED SECTION.
  PRIVATE SECTION.
ENDCLASS.

CLASS zcl_app_hello_world IMPLEMENTATION.
  METHOD z2ui5_if_app~main.
    client->message_box_display( `Hello World` ).
  ENDMETHOD.
ENDCLASS.

Open the abap2UI5 startup page in your browser — the page the Quickstart ends on — enter the class name ZCL_APP_HELLO_WORLD in the input field, press Check, and click the link that appears.

That is a complete abap2UI5 app: one class, one method, no frontend project and no OData service.

Starting an App by URL ​

The startup page is a convenience around a URL parameter you will use from now on. ?app_start=<class> appended to your service URL starts that app directly:

https://<host>:<port>/sap/bc/<your_service>?app_start=zcl_app_hello_world

That is the form a browser bookmark, a Launchpad tile and every sample catalog use — the sample pages all say "start it with ?app_start=<class>" and mean exactly this.

If launching reports Class ZCL_APP_HELLO_WORLD does not exist or does not implement z2ui5_if_app, the framework could not instantiate the class: a typo in the name, the class is not activated yet, or INTERFACES z2ui5_if_app is missing. Anything that goes wrong after this point — an app that renders empty, a binding that does not update, an error view on a roundtrip — is cataloged with symptom, cause and fix in Common Failures.

Naming

Name your own apps in your customer namespace (Z.../Y...). The Z2UI5_ prefix is reserved for the framework and its samples.

A Real Screen, an Event and Data Exchange ​

A message box is not an app. A real app has three more things: a view (the screen), data that travels to the screen and back, and an event (what the user did). This second class has all three and is still one class. You do not need to understand every line yet: the Tutorial builds exactly this, one line at a time, in its first four steps.

abap
CLASS zcl_app_hello_screen DEFINITION PUBLIC.
  PUBLIC SECTION.
    INTERFACES z2ui5_if_app.
    DATA name TYPE string.

  PROTECTED SECTION.
  PRIVATE SECTION.
ENDCLASS.

CLASS zcl_app_hello_screen IMPLEMENTATION.
  METHOD z2ui5_if_app~main.

    IF client->check_on_navigated( ).

      name = `World`.

      DATA(view) = z2ui5_cl_ui5_view_builder=>factory(
          )->ele( n = `View` ns = `mvc`
              )->a( n = `xmlns`     v = `sap.m`
              )->a( n = `xmlns:mvc` v = `sap.ui.core.mvc`

              )->ele( `Shell`
                  )->ele( `Page`
                      )->a( n = `title` v = `abap2UI5 - Hello World`

                      )->tag( `Input`
                          )->a( n = `value` v = client->_bind( name )
                      )->tag( `Button`
                          )->a( n = `text`  v = `Say Hello`
                          )->a( n = `press` v = client->_event( `SAY_HELLO` ) ).

      client->view_display( view->stringify( ) ).

    ELSEIF client->check_on_event( `SAY_HELLO` ).

      client->message_toast_display( |Hello { name }!| ).

    ENDIF.

  ENDMETHOD.
ENDCLASS.

Type a name, press the button, and the toast greets it. Four things are happening, and you wrote no JavaScript and no data transfer for any of them:

  • check_on_navigated( ) is true when the screen has to be drawn: on the first call, and whenever the user comes back to this app
  • the view is a UI5 XML view, built in ABAP with z2ui5_cl_ui5_view_builder
  • client->_bind( name ) ties the input to the public attribute, so what the user types is in name on the next roundtrip
  • client->_event( ) sends the button press back to main, and check_on_event( ) catches it

Jump into the Code ​

Press Ctrl+F12 in any running app to open the Developer Tools — the problems, every roundtrip with its request and response, the rendered view XML and the model data of the view and of every popup. It is the first place to look when something does not render the way you expected:

The Developer Tools opened with Ctrl+F12 over the Hello World app: the Overview tab with app class, draft id, last event and the view slots

Where Next ​

Next: the Tutorial. It takes these two classes apart and grows them into a complete app, one concept per step. Every step is a complete class you can run in the browser.

Later ​

  • Something does not work?Common Failures lists symptom, cause and fix.
  • Read an app that already does it. The sample catalog holds hundreds of working apps with their ABAP printed in full.
  • Look a pattern up. The Cookbook is the reference for everyday work.
  • Go live. Go-Live Checklist is the page to read before the first go-live.
  • Need somebody's approval? Send them the case for abap2UI5.

Working Samples ​

Complete apps from the sample catalog that use what this page describes. Each is a single class in abap2UI5/samples unless its row names another of the three sample repositories — pull that repository with abapGit and start the class with ?app_start=<class>.

SampleClass
Basics I — Hello World, the Smallest AppZ2UI5_CL_SMP_APP_493
